Precision Micros
Precision Micros
| Model Number: | DB3650 | Usage: | Fan, Home Appliance |
| Certification: | ROHS | Type: | Micro Motor |
| Torque: | 25mNm | Construction: | Permanent Magnet |
| Commutation: | Brushless | Protect Feature: | Drip-proof |
| Speed(RPM): | 3500rpm no load | Continuous Current(A): | 0.18A no load |
| Output Power: | 1W~100W | Voltage(V): | 12V |
| Efficiency: | IE 1 | Rated load speed: | 3000rpm |
| Rated load torque: | 25mNm | Rated load current: | 0.58A |
| Starting torque: | 162mnm | Starting current: | 2.8A |
| Motor Length: | 50±0.3mm | Shaft dia: | 4.0mm |
| Shaft length: | Customizable | Application: | Air pump |
| Packaging Detail: | 1. Export standard packing; 2. Factory standard packing; 3. Customized packaging per request. |
| Delivery Detail: | 15 days for samples, 25-30 days for batch orders. |
DC motor, DC gear motor, DC brushless motor, OEM and motor product design
Specifications & Features:
Established in 2003, we have been committed to the development and production of micro motors, including 4 major product series: Micro DC motor, DC gear motor, coreless motor, and brushless motor. Our products are widely used in consumer electronics, electric toys, household appliances, office automation, medical equipment, power tools, and automotive fields.
